Detailed Description
Table 1-29: Power Supply Voltages for HPC Connector
Voltage Supply
Allowable
Voltage Range
No Pins Max Amps Tolerance
Max Capacitive
Load
VADJ Fixed 2.5V 4 4 +/- 5% 1000 uF
VIO_B_M2C 0-VADJ 2 1.15 +/- 5% 500 uF
VREF_A_M2C 0-VADJ 1 1 mA +/- 2% 10 uF
VREF_B_M2C 0-VIO_B_M2C 1 1 mA +/- 2% 10 uF
3P3VAUX 3.3V 1 20 mA +/- 5% 150 uF
3P3V 3.3V 4 3 +/- 5% 1000 uF
12P0V 12V 2 1 +/- 5% 1000 uF
