Xilinx ML605 - Block Diagram; Related Xilinx Documents

Restoring ML605 CompactFlash
 After Restoring the CompactFlash, six designs are available:
– CFG0 – Built-In Self Test (BIST)
• See XTP056 – ML605 BIST Flash Application for details
– CFG1 – IBERT
• See XTP046 – ML605 GTX IBERT Design Creation for details
– CFG2 – MIG
• See XTP047 – ML605 MIG Design Creation for details
– CFG3 – MIG
• See UG533 – ML605 Getting Started Guide for details
– CFG5 – System Monitor
• See XTP048 – ML605 System Monitor for details
– CFG6 – FMC XM104 IBERT
• See XTP091 – ML605 FMC XM104 IBERT Design for details
Note: Presentation applies to the ML605
