ML605 Restoring Flash Contents Description
 Description
– A CompactFlash image is provided for restoring the ML605 CompactFlash
card
– The ISE iMPACT tool is used to restore the onboard non-volatile memories
with the contents used in the ML605 Getting Started Guide (UG533) for the
Platform Flash and the P30T Linear BPI Flash
 Reference Design IP
– Uses XTP044 PCIe x8 Gen1 output files to program Platform Flash
– Uses XTP056 BIST output files to program P30T Linear BPI Flash
 Reference Design Source and Applications
– See XTP044 and XTP056
 Files for Flash Restoration
– rdf0021.zip – Platform and P30T BPI Flash Devices
– rdf0022.zip – CompactFlash
– Available through http://www.xilinx.com/ml605
Note: Presentation applies to the ML605
