Xilinx ML605 - Restoring ML605 Platform and P30 T BPI Flash

Restoring ML605 Platform and P30T BPI Flash
 After Restoring the flash, two designs are loaded in Flash
– BPI – Built-In Self Test (BIST)
• See XTP056 – ML605 BIST Flash Application for details
– Platform Flash – PCIe x8 Gen1 Design
• See XTP044 – ML605 PCIe x8 Gen1 for details
Note: Presentation applies to the ML605
