Xilinx Zynq UltraScale+ User Manual

Zynq UltraScale+ VCU TRD User Guide 32
UG1250 (v2019.1) May 29, 2019 www.xilinx.com
Chapter 3: APU Software Platform
The TRD application (vcu_qt) is a multi-threaded Linux application with the following main
tasks:
• Displays unprocessed video from one or more sources.
• Applies a processing function (encode/decode).
• Provides a GUI for user input.
• Interfaces with lower level layers in the stack to control video pipeline parameters and
video data flow.
The application consists of multiple components that have been specifically developed for
the VCU TRD (see Figure 3-8). These interfaces are explained in more detail in subsequent
sections:
•GUI application (vcu_qt)
• GStreamer interface library (vcu_gst_lib)
• Video library (vcu_video_lib)
• AXI Performance Monitor (APM) library (vcu_apm_lib)
• GStreamer command line application (vcu_gst_app)
• PCIe command line app (pcie_transcode)
• PCIe library (pcie_lib)
GStreamer framework GStreamer is the cross-platform/open source multimedia framework, and
provides the infrastructure to integrate multiple multimedia components and
create pipelines. Various GStreamer plug-ins are used for input, filter, and display
components.
Table 3-1: Software Stack Components (Cont’d)
Component Description
X-Ref Target - Figure 3-8
Figure 3-8: Video Application Interfaces
vcu_qt/vcu_gst_app
vcu_gst_lib
vgst_lib.hvgst_err.h
vcu_video_lib
vcu_apm_lib
perfapm.h
video.h
video.h
X19933-112718
Send Feedback

Xilinx Zynq UltraScale+ Specifications

General

Manufacturer	Xilinx
Model	Zynq UltraScale+
Category	SoC
Processor Cores	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
FPGA Fabric	UltraScale+ FPGA
Memory Interfaces	DDR4, DDR3, LPDDR3, LPDDR4
Connectivity	Gigabit Ethernet, USB 3.0, SATA, PCIe
Video Codecs	H.264
Power Consumption	Varies depending on specific device configuration and usage
Operating Temperature	Commercial: 0°C to +85°C, Industrial: -40°C to +100°C
