Appendix B: Additional Resources and Legal Notices
References
The most up-to-date information for this design is available on these websites:
Zynq UltraScale+ MPSoC ZCU106 Evaluation Kit
Zynq UltraScale+ MPSoC ZCU106 Evaluation Kit Documentation
Zynq UltraScale+ MPSoC ZCU106 Evaluation Kit Master Answer Record (AR 69344)
H.264/H.265 Video Codec Unit IP Core website
Zynq UltraScale+ MPSoC VCU TRD wiki for 2019.1
These documents and sites provide supplemental material:
1. GStreamer open source media framework (gstreamer.freedesktop.org/)
2. ZCU106 Evaluation Board User Guide (UG1244)
3. Leopard Imaging Inc. website
4. Xilinx Software Development Kit (XSDK)
5. OpenMAX website
6. Advanced Linux Sound Architecture (ALSA) project homepage
7. Zynq UltraScale+ MPSoC Software Developer Guide (UG1137)
8. Zynq UltraScale+ Device Technical Reference Manual (UG1085)
9. Video Test Pattern Generator LogiCORE IP Product Guide (PG103)
10. Video Frame Buffer Read and Video Frame Buffer Write LogiCORE IP Product Guide
(PG278)
11. Video PHY Controller LogiCORE IP Product Guide (PG230)
12. HDMI 1.4/2.0 Receiver Subsystem Product Guide (PG236)
13. Video Processing Subsystem Product Guide (PG231)
14. MIPI CSI-2 Receiver Subsystem LogiCORE IP Product Guide (PG232)
15. Video Mixer LogiCORE IP Product Guide (PG243)
16. 10G/25G High Speed Ethernet Subsystem Product Guide (PG210)
17. AXI DMA LogiCORE IP Product Guide (PG021)
18. HDMI 1.4/2.0 Transmitter Subsystem Product Guide (PG235)
19. Intel Platform Management Field Replaceable Unit (FRU) Information Storage Definition
Send Feedback

Xilinx Zynq UltraScale+ Specifications

General

Manufacturer	Xilinx
Model	Zynq UltraScale+
Category	SoC
Processor Cores	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
FPGA Fabric	UltraScale+ FPGA
Memory Interfaces	DDR4, DDR3, LPDDR3, LPDDR4
Connectivity	Gigabit Ethernet, USB 3.0, SATA, PCIe
Video Codecs	H.264
Power Consumption	Varies depending on specific device configuration and usage
Operating Temperature	Commercial: 0°C to +85°C, Industrial: -40°C to +100°C
