Xinje DP3C Series User Manual

14
Group P2: IO configuration
Parameter
Address
Meaning
Range
Default
Note
P2-00
0x0200
-
0~65535
0
P2-01
0x0201
Z phase output
0~65535
3
Bit0~3 output terminal
Bit4 effective voltage
P2-02
0x0202
Alarm output
0~65535
1
Bit0~3 output terminal
Bit4 effective voltage
P2-03
0x0203
Brake output
0~65535
7
Bit0~3 output terminal
Bit4 effective voltage
P2-04
0x0204
In place output
0~65535
2
Bit0~3 output terminal
Bit4 effective voltage
P2-05
0x0205
Alarm clear
0~65535
6
Bit0~3 output terminal
Bit4 effective voltage
P2-06
0x0206
POT
0~65535
3
Bit0~3 output terminal
Bit4 effective voltage
P2-07
0x0207
NOT
0~65535
4
Bit0~3 output terminal
Bit4 effective voltage
P2-08
0x0208
Return to zero
0~65535
5
Bit0~3 output terminal
Bit4 effective voltage
P2-09
0x0209
Probe 1
0~65535
1
Bit0~3 output terminal
Bit4 effective voltage
P2-10
0x020A
Probe 2
0~65535
2
Bit0~3 output terminal
Bit4 effective voltage
Group P3: protection function
Parameter
Address
Meaning
Range
Default
Note
P3-00
0x0300
Tracking error
limit
1~65535
4000
For the current 1000ppr encoder,
the default is 4000 = 1 turn
P3-01
0x0301
Fault detection
selection
0~255
255
P3-02
0x0302
Under voltage
alarm
threshold
0~20
0
Shield the alarm when it is 0 in
default
Group P4: motor parameters
Parameter
Address
Meaning
Range
Default
Note
P4-00
0x0400
Peak current
305: 1~40
705: 1~70
808: 1~84
305: 25
705: 60
808: 70
Motor peak current (100mA)
P4-01
0x0401
Encoder
resolution
200~20000
4000
Quadruple frequency,
modification is not supported
P4-02
0x0402
-
0~1
0
Group 5 to group 7 are reserved.
