Xinje DP3C Series User Manual

5
1-4. Electrical specification
1-5. Safety caution
(1) The driver must be installed and operated by professional technicians!
(2) The input voltage of the driver must meet the technical requirements!
(3) It is strictly forbidden to plug and unplug the power terminal of the driver with electricity. When the motor
stops, there is still a large current flowing through the coil. Pulling and unplugging the power terminal will
produce a huge instantaneous induction, and the electric potential will burn out the driver!
(4) Before power on, please ensure the connection correctness and firmness of power cable, motor cable and
signal cable!
(5) Avoid electromagnetic interference!
Driver model
DP3C-305
DP3C-705
DP3C-808
Input power supply voltage (VDC)
20-50
20-50
20-80
Output peak current (A)
1-3
1-7
1-8
Matched motor (base)
42
57/60
86
Input signal
Probe input, origin input, positive and negative limit,
emergency stop, user-defined input
Output signal
Alarm output, in place output, holding brake signal output,
custom output
Alarm function
Overcurrent, overvoltage, out of tolerance, abnormal
communication, etc
Debugging software
Xinje stepper driver software
Using
environment
Application area
Try to avoid dust, oil mist and corrosive gas, places with
high humidity and strong vibration, and combustible gas and
conductive dust are prohibited
Environment
temperature
0℃~50℃
Max working
temperature
60℃
Humidity
40%~90% RH (No condensation or water droplets)
Vibration
5.9m/s
2
Max
Storage
temperature
-20℃～65℃
