Xinje DS2-20P4-AS User Manual

SI2
0013: input negative signal to
SI3
0014: input negative signal to
SI4
0015: input negative signal to
SI5
0016: input negative signal to
SI6
11
/P-CON proportion action
command ditto
－
※1
※3
●
All the
modes
5-5-4
12
/P-OT forward drive prohibition
ditto
－
※1
※3
●
All the
modes
5-2-3
13
/N-OT reverse drive prohibition
ditto
－
※1
※3
●
All the
modes
5-2-3
14
/ALM-RST alarm reset
ditto
－
※1
※3
●
All the
modes
5-11-1
15
/P-CL forward external torque
limit
ditto
－
※1
※3
●
All the
modes
5-5-7-2
16
/N-CL reverse external torque
limit
ditto
－
※1
※3
●
All the
modes
5-5-7-2
17
/SPD-D internal speed selection
ditto
－
※1
※3
●
1,2,3,4
5-6-3
18
/SPD-A internal speed selection
Same to above
－
※1
※3
●
3,5,6
5-6-3
19
/SPD-B internal speed selection
ditto
－
※1
※3
●
3,5,6
5-6-3
20
/C-SEL control mode selection
ditto
－
※1
※3
●
All the
modes
5-10
21
/ZCLAMP zero clamp
ditto
－
※1
※3
●
3,5
5-5-5
22
/INHIBIT command pulse
prohibition
ditto
※1
※3
●
5,6
5-3-8
23
/G-SEL gain switch
ditto
－
※1
※3
●
All the
modes
6-1-5
24
/CLR clear pulse offset
ditto
－
※1
※3
●
5,6
5-3-5
25
/CHGSTP step change signal
ditto
－
※1
※3
●
5
5-4-4
26
Reserved
27
Reserved
28
/COIN positioning finished
0000: not output to the terminal
0001: output positive signal
from SO1
0002: output positive signal
from SO2
0003: output positive signal
from SO3
0011: output negative signal
from SO1
0012: output negative signal
－
※2
※4
●
5,6
5-3-6
