Xinje DS3 Series Manual

48
Servo drive
Regenerative resistor connection terminals
DS3-2□P□-PQA
DS3E-2□P□-PFA
DS3-4□P□-PQA
DS3E-4□P□-PFA
for internal regenerative resistor: short P+ and D, disconnect P+ and
C, P0-24=0.
for external regenerative resistor: connect resistor between P+ and C,
disconnect P+ and D, P0-24=1, P0-25=power value, P0-26=resistor
value.
Parameter
Signal
name
Setting
Meaning
Effective
Modify
P0-24
Choose
regenerative
resistor
0
Use internal regenerative
resistor
At once
Servo OFF
1
Use external regenerative
resistor (resistor type please
refer to the following table)
Parameter
Signal name
Setting
Unit
Effective
P0-25
Discharge
resistor
power
1. self-cooling mode (natural convection
cooling): below 20% of regenerative
resistor capacity (W)
2. forced air cooling: below 50% of
regenerative resistor capacity (W)
W
At once
P0-26
Discharge
resistor
value
Resistor value
Ω
At once
The following table shows the recommended specifications of the external regenerative
resistance for each type of motor.
