Xinje DS3 Series Manual

49
Servo drive
Min resistor
(cannot smaller than
this value)
External
regenerative resistor
(recommend value)
External
regenerative resistor
(recommend power)
DS3-20P2-PQA
DS3E-20P2-PFA
≥50Ω
50Ω—100Ω
≥200W
DS3-20P4-PQA
DS3E-20P4-PFA
≥40Ω
40Ω—100Ω
≥500W
DS3-20P7-PQA
DS3E-20P7-PFA
≥40Ω
40Ω—100Ω
≥500W
DS3-21P5-PQA
DS3E-21P5-PFA
≥25Ω
25Ω—50Ω
≥1000W
DS3-22P3-PQA
DS3E-22P3-PFA
≥25Ω
25Ω—50Ω
≥1000W
DS3-41P5-PQA
DS3E-41P5-PFA
≥55Ω
55Ω—100Ω
≥1000W
DS3-43P0-PQA
DS3E-43P0-PFA
≥55Ω
55Ω—75Ω
≥1000W
DS3-45P5-PQA
DS3L-45P5-PQA
≥25Ω
25Ω—65Ω
≥2000W
DS3-47P5-PQA
DS3L-47P5-PQA
≥25Ω
25Ω—50Ω
≥2000W
DS3-411P0-PQA
DS3-415P0-PQA
≥18Ω
18Ω—45Ω
≥3000W
1. The temperature will be very high when the regenerative resistor is discharging, please
using heat-resistant non-flammable wire. Don’t touch the regenerative resistor when wiring.
2. When you choose the regenerative resistor, please make the resistor value close to the min
value of recommend value. The resistor power is decided by the actual consition specially the
heat.
