Xinje DS3 Series - User-defined output signal

86
xxx□
times after leaving
the limit
switch(stop when
n+1 Z phase signal
arrived)
0.
xx□x
Find origin function
0: OFF 1: ON
-
0
0~1
○
5, 6
01
Hit proximity
switch speed
0.1rpm
600
0~50000
○
5, 6
02
Leaving proximity
switch speed
0.1rpm
100
0~50000
○
5, 6
03
Internal position
mode
-
n.0000
○
5, 6
04
Effective segment
number
-
1
1~35
○
5, 6
10
First segment pulse
(low byte)
1 pulse
0
-9999~9
999
○
5, 6
11
First segment pulse
(high byte)
10000
pulse
0
-32767~
32767
○
5, 6
12
First segment speed
0.1rpm
0
0~10000
○
5, 6
13
First segment
acceleration time
1ms
0
0~65535
○
5, 6
14
First segment
deceleration time
1ms
0
0~65535
○
5, 6
15
Reserved
16
Adjustment time
1ms
0
0~65535
○
5, 6
P4-17~P4-23 are internal position segment 2 parameters, the following total 35 segments.
