Xinje DS5L Series - Page 35

Ø114. 3h7
96
3
19
113± 0. 5
LA
Ø42h6
4- ∅ 13. 5 ∅ 200
a180
12
- 0 - 0. 1
P9
M16 - 6H 32
37
0. 0
- 0. 1
Motor model
LA±1
Inertia
level
Normal
With
brake
MS6H-180C□15B□2-45P5 269 309
High
inertia
MS6H-180TL15B□2-45P5 269 309
MS6H-180C□15B□2-47P5 325 365
MS6H-180TL15B□2-47P5 325 365
Ø35h6
Ø114. 30h7
65
3
79± 0. 50
19
LA
∅ 200
4- ∅ 13. 5
a180
M12 - 6H 16
10
- 0. 02 - 0. 05
P9
30
0. 00
- 0. 10
Motor model
LA±1
Inertia level
Normal
With
brake
MS6H-180CS/CM15E□2-45P5 269 309
High inertia
MS6H-180CS/CM15E□2-47P5 325 365
28
