Xinje DS5L Series

6
）
14 Denominator of Electronic Gear - 1 0~65535 ○ 5|6
15
pulse frequency corresponding to rated
speed
100Hz 1000 1~10000 ○ 7
16 speed command pulse filter time 0.01ms 100 0~10000 ○ 7
23 pulse offset limit
0.01
turns
2000 0~65535 √ 5|6|10
24.0
Type selection of discharge resistance
(version 3640 and before)
0 - built in
1 - external
Discharge resistance power protection
mode (version 3700 and later)
0 - cumulative discharge time
1 - average power mode 1
2 - average power mode 2
- 0 0~2 ○
1|3|5|6|7|8|
9|10
25 Power Value of Discharge Resistance W
Set as
the
model
1~65535 ○
1|3|5|6|7|8|
9|10
26 Discharge resistance value Ω
Set as
the
model
1~500 ○
1|3|5|6|7|8|
9|10
P0- Function Unit Default value Range Effective Suitable mode
27
Servo shutdown the enable stop mode
0-Inertial Operation Stop
2-deceleration stop
- 0 0~5 ○ 1|3|5|6|7|8|9|10
28 Servo overtravel stop mode (P0-28.0)
0 - deceleration stop 1
1 - inertia stop
2 - deceleration stop 2
3 - alarm stop
Overtravel alarm shield switch (P0-28.1)
-
2 0~3
○ 1|3|5|6|7|8|9|10
0 0~1
92
