Xinje MP Series User Manual

47
Suitable model：MP330-S
3-10．Facon FB series
1. Software settings
parameters
Recommended settings
MP communication port
Communication port
PLC communication port
Communication port/expanded communication port
Communication type
RS232
Communication distance
15m
Data bit
7
Stop bit
1
Verification mode
Even
Baud rate
9600
Modbus number
1
2. Address
PLC address
Operational
range
Data type
Description
M
0~2001
Bit
Internal auxiliary coil
X
0~255
Bit
External input coil
Y
0~255
Bit
External output coil
S
0~999
Bit
Sequential control coil
T
0~255
Bit
Timer
C
0~255
Bit
Counter
R
0~9000
Word/D word
Data registers
X
0~255
Word/D word
Registers
Y
0~255
Word/D word
Registers
M
0~2001
Word/D word
Registers
S
0~999
Word/D word
Registers
D
0~3071
Word/D word
Registers
TD
0~255
Word/D word
Registers
C16
0~199
Word/D word
16 counter
C32
200~255
Word/D word
32 counter
T
0~255
Word/D word
Designated timer status
