Xinje MP Series User Manual

4
1-1-3. Types
Model
Description
MP330
3.7’’, Kelly LCD, 192*64, 26 function buttons, touch screen, RS422
MP330-S
3.7’’, Kelly LCD, 192*64, 26 function buttons, touch screen, RS485
MP325-A
3.7’’, Kelly LCD, 192*64, 20 function buttons, touch screen, RS422
MP325-A-S
3.7’’, Kelly LCD, 192*64, 20 function buttons, touch screen, RS485
MP360-L
3.7’’, blue LCD, 192*64, 26 function buttons, touch screen
MP760-T
7’’, 256 true colours TFT, 480*234, 26 function buttons, touch screen
1-2．General specifications
Electric specifications:
Item
Specification
MP330(-S)
MP325-A(-S)
MP360-L
MP760-T
Electric
Input voltage
DC24V
Consumption current
<140mA
<240mA
Allowable power-off
<10s (less than 1s in fact)
Withstand voltage
impact
AC1000V, 20mA, less than 1 minute
Insulated resistor
10MΩ, DC500V (signal and ground)
Ambient
Operate temperature
0℃～50℃
Storage temperature
–20℃～60℃
Ambient temperature
10~90% (no condensation)
Noise immunity
1000Vp-p, pulse period 1ms, last time 1 minute
Ambient air
No corrosive gas
Protection
IP20
Structure
Cooling mode
Natural cooling
External dimension
172*121*56.5
172*94*40
172*121*56.5
214*200*60.3
Mounting dimension
164*113
164.2*86.8
164*113
201*187
Port
Download port
RS232
Com port
RS232/422
(-S: RS232/485)
RS232/422
(-S: RS232/485)
RS232/422/485
