Xinje XC Series Hardware Manual

Appendix 1 special soft device list
ID
Counter
ID
Function Description
M8150 C600 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8151 C602 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8152 C604 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8153 C606 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8154 C608 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8155 C610 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8156 C612 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8157 C614 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8158 C616 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8159 C618 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8160 C620 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8161 C622 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8162 C624 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8163 C626 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8164 C628 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8165 C630 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8166 C632 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8167 C634 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8168 C636 “Count Interruption Finished” Flag Set flag ON when count interruption finish
M8169 C638 “Count Interruption Finished” Flag Set flag ON when count interruption finish
ID Pulse ID Function specification
M8170 PULSE_1 “sending pulse” flag Being ON when sending the pulse,
M8171
overflow flag of “32 bits pulse
sending”
When overflow, Flag is on
M8172 Direction flag
1 is positive direction, the correspond
direction port is on
M8173 PULSE_2 “sending pulse” flag Being ON when sending the pulse,
M8174
overflow flag of “32 bits pulse
sending”
When overflow, Flag is on
M8175 Direction flag
1 is positive direction, the correspond
direction port is on
M8176 PULSE_3 “sending pulse” flag Being ON when sending the pulse,
M8177 overflow flag of “32 bits pulse When overflow, Flag is on
“High Speed Counter Interruption Finished” Flag (M8150-M 8169)
Pulse output (M8170~M8238)
