Xinje XP3-18R - Parts Explanation

13
Flash ROM Register（FD） 510 words 512 words 2048 words
Extension D register (ED) - - 16383
High speed processing
function
- High speed count, pulse output,
external interrupt
Setting of time scan space 0~99mS
Password protection 6 bits ASCII
Self diagnose function Power on self-diagnose, Monitor timer, grammar check
Note: The user program capacity is referred to the capacity under “secret downloading mode”.
1-3. Parts explanation
Configuration
5 6 7 8
4321
01
2 3 4 5
9876
Number
key
Screen area
Function
key
