3. PLC function and application
3-1. PLC instruction
The XP/XMP integrated with XC series PLC. The function of PLC is the same as XC series.
XP/XMP Type Integrated PLC type
XP1/XMP1 series XC1 series
XP2/XMP2 series XC2 series
XP3/XMP3 series XC3 series
1. XP1/XMP1 series include SFC instructions and applied instructions, exclude special function
instructions.
2. XP2/XMP2 series and XP3/XMP3 series have the same instructions. They include SFC
instructions, applied instructions and special function instructions.
Please refer to XC Series PLC Manual: paragraph 4, 5, 6.
XP2/XMP2 and XP3/XMP3 have special function instructions, please refer to XC Series PLC
Operating Manual: paragraph 6. Here we only give the port definition and distribution.
1. High speed count
XP2/XMP2/XP3/XMP3 series
Increase mode Pulse+direction mode AB phase mode
C600C602 C604 C606 C608 C610 C612 C614 C616 C618 C620 C622 C624 C626 C628 C630 C632 C634
Highest
frequency
80K 80K 10K 10K 10K 80K 10K 10K 80K 5K 5K
4 times
frequency
√ √
Count
interruption
√ √ √ √ √ √ √
X000 U U A
X001 U Dir B
X002
X003 U U A
X004 Dir B
X005
X006 U U A
X007 Dir B
Instruction
Special function instructions
