24
2. High speed pulse output
u T type: Y0, Y1 available, the highest frequency is 200KHz
u RT type: Y0, Y1 available, the highest frequency is 200KHz
u R type: unavailable
3. Interrupt function
Pointer tag
Channel Input
Rising interruption Falling interruption
Disable interruption
instruction
CHL1 X2 I0000 I0001 M8050
CHL2 X5 I0100 I0101 M8051
CHL3 X10 I0200 I0201 M8052
4. Frequency measurement
The point is X1, X11, X12.
5. Pulse width modulation
The point is Y0, Y1.
u T type: Y0, Y1 available
u RT type: Y0, Y1 available
u R type: unavailable
6. Precise timer
32 bit precise timer, the timer range is T600 to T618, match with 10 interruption tag.
3-2. soft component range
XP/XMP series soft component ID distribution list is as below:
If extending BD board, the in-out point definition, please refer to XP Series Extended BD Board
Manual.
X010
X011 U
X012
