Xinje XP3-18R - Outline Dimension

15
DB9 pins DB9 pins
XP/XMP PC
2 RXD 2 RXD
3 TXD 3 TXD
5 GND 5 GND
7 RTS 7 CTS
Communication port ( A and B ) is a RS-485 com port. This port is used to connect other devices.
Please refer to paragraph 3-4 for details.
1-4. Outline dimension
Unit: mm
Communication port
Outline dimension
121
162
111
56.5
172
6 7 8 9
5432
1 0
1 2 3 4
8765
