42
5-2. Extend MA model
XP/XMP can extend MA model via RS-485 com port (A and B point) in order to control and
measure analog quantity.
The type and specs of MA model are as below:
Type Function
MA-8X8YR 8 channels digital input, 8 channels digital output
MA-16X 16 channels digital input
MA-16YR/T 16 channels digital output
MA-4DA 4 channels analog output
MA-4AD 4 channels analog input
MA-8AD-A/V 8 channels analog input
MA-4AD2DA 4 channels analog input, 2 channels analog output
MA-6TC-P 6 channels type K thermocouple temperature control
MA-6PT-P 6 channels PT100 temperature control
Type Description
MA-8X8YR 8 channels digital input,8 channels
digital relay output
MA-16X 16 channels digital input
MA-16YR
16 channels digital relay output
MA-16YT 16 channels digital transistor output
MA-4DA
Item Voltage output Current output
DC0～5V、0～10V DC0～20mA、4～20mA
Analog output range
( exterior load resistor
2KΩ~1MΩ)
(exterior load resistor less than
500Ω)
Digital input range 10 bits binary numbers
Resolution ratio 1/1023（10Bit）
Integrated precision
0.8%
Conversion speed 3ms/1 channel
Power of analog quantity DC24V±10%，100mA
Installation Use M3 screw or fix on DIN46277 rail ( width 35mm )
MA model type
MA model specs
