5. The extension ability of XP/XMP
5-1. Extend BD board
XP3/XMP3 series product (exclude XMP2-32R/T-E ) can extend XP3 series BD board via the
insertion groove at the back in order to control and measure the analog quantity.
The specs and type of BD board is as below table:
Type Function
XP3-2AD2PT-BD 2 channels analog input
2 channels PT100 temperature measurement
XP3-2TC-P-BD 2 channels K thermocouple temperature measurement
PID adjustment inside
XP3-2PT2AD1DA-BD 2 channels PT100 temperature measurement
2 channels analog input
1 channel analog output
XP3-2AD2PT-BD:
Item Voltage input Temperature input
Analog input
signal
DC0~5V、0~10V（Input resistor 300k
Ω）
Platinum resistor Pt100（2-line
format）
Temperature
measurement
range
- -100~350℃
Distinguish ratio 0.15mV（10/16383） 0.1℃
Digital output
range
0~16383 -1000~3500
Integrated
precision
±0.8% of the full-scale
Convert time 15ms×4 channels
PID output value 0~K4095
Empty loader
defaulted value
0 3500
BD board type
BD board specs
