Xinje XP3-18R User Manual

26
XP2/XMP2 and XP3/XMP3 series:
Range Point
Soft
component
Name
XP2/XMP2 XP3/XMP3 XP2/XMP2 XP3/XMP3
X Input point X000~X011(octal) 10
Y
Output
point
Y000~Y007(octal) 8
M0~ M2999
【M3000~M7999 】
8000
M
Auxiliary
relay
M8000~M8767 768
S Status
S0~ S511
【S512~M1023 】
1024
T0~T99：100ms not accumulation
T100~T199：100ms accumulation
T200~T299：10ms not accumulation
T300~T399：10ms accumulation
T400~T499：1ms not accumulation
T500~T599：1ms accumulation
T600~T618：1ms with interruption precise time
T Timer
T620~T639：vacant
640
C0~C299：16 bits forth counter
C300~C318：32 bits forth/back counter
【C320~C598】：32 bits forth/back counter
【C600~C619】：one phase high speed counter
【C620~C629】：
Pulse + direction high speed
counter
C Counter
【C630~C639】：AB phase high speed counter
640
D0~D999
【D4000~D4999】
D0~ D3999
【D4000~D7999】
2000 8000
D
Data
register
For special using
D8000~D8511
D8630~D8729
For special using
D8000~D9023
612 1024
FD0~FD127 FD0~FD1535 128 1536
FD
FlashROM
register
For special using
FD8000~FD8383
For special using
FD8000~FD8511
384 512
ED
Extend data
register
- 【ED0~ED16383】 - 16384
NOTE:
※1. The memorizer area in 【 】 is the defaulted power failure retentive area, the power
failure retentive area of soft components D, M, S, T, C can be set via FD register. For
the details, please see the following table.
※2. Flash ROM register needn’t set power failure retentive area, its data won’t lose when
