Xray T4 2018 User Manual

4
NOT INCLUDED
To ensure that you always have access to the most up-to-date version
of the XRAY Set-up Book, XRAY will now be offering only the digital
online version on our website www.teamxray.com. By offering this online
version instead of including a hardcopy printed version in kits, you will
always be assured of having the most current updated version.
XRAY offers wide range of optional tuning parts which are listed in tables
like these. Please refer to the exploded view of each main section to
verify which part is included in the kit while all other parts are available
only as an optional part and must be purchased separately.
TOOLS REQUIRED
Side Cutters
(HUDY #189010)
Turnbuckle Wrench
4mm (HUDY #181040)
Reamer
(HUDY #107600) or
(HUDY #107601)
Combination Pliers
(HUDY #189020)
HUDY TOOLS:
Scissors
(HUDY #188990)
4.0 mm
Socket: 5.5mm Socket: 7.0mmAllen: 1.5mm Allen: 2.0mm Allen: 3.0mmAllen: 2.5mm
Pocket Hobby Knife
(HUDY #188981)
RC Shock-Plier Uni Tool
(HUDY #183011)
Arm Reamer 3.0mm
SYMBOLS USED
L=R
2x
CA
OIL
Part bags used Assemble left and
right sides the
same way
Assemble in the
specified order
Pay attention
here
Assemble as many
times as specified
(here twice)
Apply CA glue
EQUIPMENT REQUIRED
ITEMS INCLUDED
Apply oil
Optional
parts
Premium Silicone Oil
400cSt (HUDY #106340)
400cSt
3000cSt
Premium Silicone Oil
3000cSt (HUDY #106430)
TL
05
Tighten screw
gently
Completed
assembly
Detail view
Apply thread
lock
Apply greaseScale Ensure smooth
non-binding
movement
Graphite Grease
(HUDY #106210)
Follow Set-up Book
FRONT & REAR AXLES
SAMPLE OF
OPTIONAL PARTS
#30XXXX OPTION 1
#30XXXX OPTION 2
#30XXXX OPTION 3
1:1
DETAIL
Pinion Gear and Setscrew
Transmitter Steering ServoReceiver
Bearing Oil
(HUDY #106230)
Speed Controller
Electric Motor &
Lexan™ Paint Battery Charger
Wheels & Tires & Inserts
LiPo Battery190mm Bodyshell
Fibre Tape
(HUDY #107870)
Double-sided Tape
(HUDY #107875)
