At the beginning of each section is an exploded view of the parts to be assembled. There is also a list of all the
parts and part numbers that are related to the assembly of that section.
The part descriptions are color-coded to make it easier for you to identify the source of a part. Here are what
the different colors mean:
Style A - indicates parts that are included in the bag marked for the section.
STYLE B - indicates parts that are included in the box.
STYLE C - indicates parts that are already assembled from previous steps.
CHASSIS PREPARATION
COLOR INDICATIONS
To protect and seal edges of graphite parts, sand edges smooth and then apply CA glue.
Do this for: chassis edges, countersunk holes, and shock towers.
Apply only a bit of CA glue in the countersunk holes.
Apply only a bit of CA glue in the countersunk holes.
