Page #10 background image
10
LOWER ARMS
VIDEO TECH TIP
▶
901310
SB M3x10
901408
SB M4x8
SUSPENSION ARMS
SUSPENSION ARMS
SUSPENSION ARMS
Make sure to use 10mm set
screw for rear arms.
LEFT = RIGHT
L=R
2.6mm
2. FRONT & REAR SUSPENSION
5.0mm
DETAIL
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
3x10mm
4x8mm
Install the pivot balls with Professional
Multi Tool (HUDY #183011).
Install the pivot balls with Professional
Multi Tool (HUDY #183011).
Press
straight
Press
straight
