Xray X4 User Manual

6
1. GEAR DIFFERENTIAL & FRONT SOLID AXLE
981210
P 2x10
972050
O 5x2
964050
S 5x15x0.3
➊
➋
➌
➍
➍
➍
➎
➎
DETAIL
➎
STEP
304901 X4 GEAR DIFFERENTIAL - SET
304911 X4 COMPOSITE GEAR DIFF. CASE WITH 38T PULLEY & COVER
304930 COMPOSITE GEAR DIFF BEVEL & SATELLITE GEARS (2+4)
304970 ALU GEAR DIFF OUTDRIVE ADAPTER - 7075 T6 (2)
304980 COMPOSITE GEAR DIFF CROSS PIN
304990 DIFF GASKET (4)
305134 STEEL SOLID AXLE DRIVESHAFT ADAPTER - HUDY SPRING STEEL™ (2)
305178 X4 COMPOSITE SOLID AXLE 38T
902310 HEX SCREW SH M3x10 (10)
903258 HEX SCREW SFH M2.5x8 (10)
941015 BALL-BEARING 10x15x4 RUBBER SEALED - OIL (2)
964031 WASHER S 3.5x10x0.2 (10)
964050 WASHER S 5x15x0.3 (10)
971240 SILICONE O-RING 24x0.7 (10)
972050 SILICONE O-RING 5x2 (10)
981210 PIN 2x10 (10)
GEAR DIFFERENTIAL
BAG
304970
304911
964050
972050
304990
304911
903258
981210
981210
304970
941015
971240
972050
964031
304980
304930
304930
941015
305178
COMPOSITE SOLID AXLE
305134
305178
305134
941015
902310
941015
902310
#304932
GRAPHITE GEAR DIFF BEVEL &
SATELLITE GEARS (2+4)
#304932
GRAPHITE GEAR DIFF BEVEL &
SATELLITE GEARS (2+4)
DETAIL
#309003
SET OF CERAMIC BALL-BEARINGS (14)
#304971
HUDY SPRING STEEL™ OUTDRIVES (2)
#304971
HUDY SPRING STEEL™ OUTDRIVES (2)
#305137
STEEL LIGHTWEIGHT SOLID AXLE
DRIVESHAFT ADAPTERS HUDY
SPRING STEEL™(2)
If the diff is not turning freely after
assembly, use thin sand paper to
lightly polish the surface.
#305136
ALU SOLID DRIVESHAFT ADAPTERS (2)

Xray X4 Specifications

General

Scale	1/10
Power Source	Electric
Drivetrain	4WD
Motor Type	Brushless
Drive Type	4WD
Battery Type	LiPo
Battery Voltage	7.4V
Radio System	2.4GHz
Tire Type	Rubber (Not Included)
Body Material	Polycarbonate
