19
CHASSIS & TOP DECKS
VIDEO TECH TIP
▶
903305
SFH M3x5
902314
SH M3x14
903305
SFH M3x5
902306
SH M3x6
303125-K
SHIM 3x6x3
Do not tighten the screw fully at first.
Only tighten the screws fully after
the shock tower is mounted with all
screws.
Do not tighten fully.
Tighten fully after assembly.
Do not tighten fully.
Do not use for
initial setting
3mm
IMPORTANT
3. CENTRAL TRANSMISSION
NOTE
ORIENTATION
This graphite brace reduces flex in the front of the car. The
brace will increase initial steering response but will reduce
grip from mid corner to exit. The brace is recommended for
any conditions that benefit from aggressive initial response
and is more precise to drive. The brace also increases stability
on bumpy tracks.
The initial setting is to run without this brace.
FRONT CROSS BRACE
FRONT BULKHEADS GRAPHITE BRACE
The cross brace reduces front chassis flex and improves
steering response. Recommended for most conditions EXCEPT
for higher-traction conditions or high-speed tracks where a
smoother steering response is preferred.
