37
903308
SFH M3x8
903310
SFH M3x10
960030
N M3
902312
SH M3x12
ALU SHIM 4x6x2mm
#301232
FOAM BUMPER - HARD
REARWARD CENTER
(INITIAL SETTING)
BODY POST ORIENTATION
3x10mm
It is important to use the same body
setting (rearward and center) on
both front and rear body posts at the
same time.
This new, innovative & unique feature
allows adjustment of the body position
for all kind of surfaces, traction conditions,
touring classes, using only one body.
There are two different body positions;
rearward and center. Depending on the
conditions the body post positions can be
easily changed which allows the body to
be moved.
• The body in the REARWARD POSITION
makes the car super stable and very
easy to drive. It makes the car easier to
drive in chicanes and more predictable
in high-traction conditions.
• The body in the CENTER POSITION
makes the car more aggressive and
steer faster, but is a bit more difficult to
drive in low-grip conditions.
3x10mm
3x8mm
3x10mm
3x10mm
#301210
GRAPHITE UPPER HOLDER FOR BUMPER 2.5mm
(Alu shim 4x6x2mm - INCLUDED)
FRONT BODY MOUNT SET
#301322 0mm INCLUDED
#301323 +1mm OPTION
#301324 +2mm OPTION
FRONT ECC. BODY MOUNT SET
#301326 0mm OPTION
#301327 +1mm OPTION
#301328 +2mm OPTION
DETAIL
INITIAL
SETTING
INITIAL SETTING
7. FRONT & REAR ASSEMBLY
Position WITHOUT graphite brace Position WITH graphite brace
