39
SHOCK SHIMMING
TUTORIAL
VIDEO TECH TIP
▶
REAR BODY POST
MOUNTING
VIDEO TECH TIP
▶
303123-K
SHIM 3x6x2
981212
P 2x12
902308
SH M3x8
902306
SH M3x6
NOTE
ORIENTATION
(INITIAL SETTING)
The optional horizontal rear body mounting has proven beneficial for medium- to high-
grip conditions, and especially on technical tracks. The horizontal mounting improves the
direction change of the car, improves steering response, and improves rotation. However,
rear grip is reduced. This is particularly useful for spec classes such as Stock and Super Stock.
The kit carbon mounts allow for the height of the horizontal posts to be adjusted.
7. FRONT & REAR ASSEMBLY
L=R
2x
#301351-O
ALU ADJUSTABLE BODY POST STOP (2)
Very handy, easily externally adjustable body
post made from Swiss 7075 T6 aluminum. Allows
for adjustment of body height by 3mm without
needing to change the position on the body post.
REAR BODY MOUNT SET
#301336 0mm INCLUDED
#301337 +1mm OPTION
#301338 +2mm OPTION
INITIAL SETTING
DETAIL
2mm
#308029
ULP ALU PROGRESSIVE SHOCK SYSTEM - SET (2)
The progressive shocks improve traction and steering characteristics.
This ULP progressive system directly fits the ULP shocks in the kit.
The progressive shock inserts can improve traction and
steering characteristics. The ULP PSS set fits the stock
ULP shock bodies included in the kit.
C=2.5-2.8
903306
SFH M3x6
903306
SFH M3x6
FRONT BODY MOUNT SET
#301322 0mm INCLUDED
#301323 +1mm OPTION
#301324 +2mm OPTION
REAR VERTICAL BODY MOUNTING
REAR HORIZONTAL BODY MOUNTING
