29
903308
SFH M3x8
907206
SP M2x6
903308
SFH M3x8
903310
SFH M3x10
960030
N M3
902308
SH M3x8
902310
SH M3x10
903308
SFH M3x8
Route steering servo
lead behind the personal
transponder
NOTE ORIENTATION
902310
SH M3x10
Personal transponder
(not included)
Ensure the throttle servo is not
touching the chassis. If necessary
use shims to alter the height of the servo.
Follow the TECH TIP on page
5 to protect graphite parts
DETAIL
RADIO CASE
Route servo leads as shown
Route receiver wire through
mounting hole in top plate
and through antenna tube.
KO PROPO
SANWA
FUTABA
Use appropriate servo stands
Servo screw
NOTE
ORIENTATION
Route servo leads through
this gap. Seal gap with
silicone after leads are all
routed and plugged into
receiver.
Note orientation of servo arm when servo is at neutral
Servo
stands
Use foam to cushion the
inside of the radio case so
the receiver and battery
cannot vibrate or move.
SH 3x8
3x10
3x10
#356050 Option switch
3x8
2x6
SH 3x10
SH 3x12
SFH 3x10
SFH 3x8
step
step
SH 3x8
SFH 3x8
