SYMBOLS USED
L=R
2x
CA
OIL
Part bags used Assemble left and
right sides the
same way
Assemble in the
specified order
Pay attention
here
Assemble as
many times
as specified
(here twice)
Apply instant
glue
Cut off shadded
portion
Cut off
remaining
material
Tighten screw
gently
TOOLS REQUIRED
EQUIPMENT REQUIRED
TOOLS & EQUIPMENT INCLUDED
Assemble front
and rear the same
way
Apply oil
Use special
tool
Silicone Shock Oil Silicone Diff Oil Air Filter Oil
Receiver Pack
Transmitter
.21 Engine Manifold
Exhaust
Glow Plug IgniterStarter Box & Battery Pack
Steering and
Throttle Servos
Battery Charger
Receiver
Lexan PaintFuel
Special Tool for all turnbuckles, nuts
CA Glue
Phillips 5.0mm
(HUDY #165049)
Socket 5.0 / 5.5mm
(HUDY #170058/#170059)
Allen 1.5 / 2.0 / 2.5mm
(HUDY #111549/#112049/#112549)
17mm Wheel Nut Tool
(HUDY #107570)
Side Cutters Hobby Knife Body Reamer
(HUDY #107600)
Cross wrench
(HUDY #107581)
Flywheel Tool
(HUDY #182010)
ScissorsNeedle Nose Pliers
➊➋➌
Apply grease Apply
threadlock
Ensure smooth
non-binding
movement
Use pliers Follow tip here
ARM REAMER 3mm/4mm
(HUDY #107633/#107634)
Graphite Grease
(HUDY #106210)
Transmitter Batteries
Threadlock
Follow Set-Up
Book
Use cleaner
GEAR DIFF
Time
To Next Page
