22
903412
SFH M4x12
FRONT
&
REAR
ASSEMBL
Y
35 1106
XB9
ALU CHASSIS - HARDCOATED SWISS
7075 T6 (3MM)
35 1200
FRONT
& REAR BUMPER
- V2
35 3088
COMPOSITE
REAR BRACE -
V2
90 2316
HEX
SCREW SH
M3x16
(10)
90 3312
HEX
SCREW SFH
M3x12
(10)
90 3412
HEX
SCREW SFH
M4x12
(10)
96 0030
NUT
M3 (10)
BAG
902316
960030
903412
903312
903412
351200
351106
353088
960030
351200
21
23
Table of Contents
Safety Precautions
2
Symbols Used
4
Tools Required
4
Equipment Required
4
Graphite Parts
5
Very Important
7
Center Differential
8
Front Transmission
10
Rear Transmission
11
Rear Suspension
12
Front Suspension
17
Front & Rear Assembly
22
Radio Case
31
Shock Absorbers
33
Final Assembly
36
Throttle Linkage Adjustment
39
Troubleshooting Guide
42
