XS Instruments 7 Vio User Manual

11
Rev. 1.0 30.01.2020
EN
• LED
All the instruments are equipped with a two-colours LED (red and green) which provides the user with
important information on the status of the system:
Function
LED
Description
Power on
Fixed
Power off
Fixed
Standby
Flashing every 20 s
Stable measure
Flashing every 3 s
Errors during calibration
Flashing every 1 s
Errors during measurement
Flashing every 3 s
Selection confirm
Switched on for 1 s
Timed screens
Fixed
DHS deactivation
Fixed
Installation
• Supplied components
The instrument is always supplied inside the specific carrying case; the version without sensor is
always supplied with:
instrument with batteries, 1m S7 / BNC connection cable, NT55 temperature probe, buffer solutions in
single-dose bottle and / or sachet, paper tissues, screwdriver, beaker, electrode holder support -only for
multiparameter- multilingual user manual and test report.
There are versions with the sensor(s) already included. Contact your local distributor to be updated on the
correct composition of the sales kit.
• Start-up
• The device leaves the factory ready to be used by end-user.
• Batteries are included.
• Turning On and Off
Turn on the system by pressing the button . The display initially activates all segments and then
appears:
• model and firmware of the instrument;
• settings relating to the most important parameters and possible information about the DHS sensor;
• the instrument switches on at the last parameter used.
To switch off the instrument, press the key in measure mode.
