22
Rev. 1.0 30.01.2020
• fourth and possibly fifth screen: Slope% in the measuring range (one Slope% only if two calibration
points are performed, two Slope% if three points are performed).
• When the DHS electrode is recognized, the active calibration on the instrument becomes the one of the
sensor.
• The icon on the display indicates that the connection was successful.
• If the calibration is satisfactory (see the calibration data in menu P.1.6), the electrode is ready to start
the measurements. Otherwise, recalibrate the electrode; the data will be updated automatically.
• The DHS electrode calibrated with a pH 7 Vio or PC 7 Vio device is ready to be used on any pH meter
enabled for DHS recognition and vice versa.
• When the electrode is disconnected, a message on the display informs the user of the deactivation of
the sensor; the instrument regains its previous calibration and no data is lost!
• The DHS electrode does not require batteries and if it is used on pH meters that are not enabled to
recognize the chip, it works as a normal “analog” electrode.
• Errors during calibration
• NOT STABLE: The button was pressed with still unstable signal. Wait for the icon to appear
to confirm the point.
• WRONG BUFFER: The buffer is polluted or not part of the recognized families.
• SLOPE OUT OF RANGE: The slope of the sensor calibration line is out of the acceptable range 80 - 120%.
• CALIBRATION TOO LONG: The calibration exceeded the time limit: only the points calibrated up to that
moment will be kept.
mV Parameter
pH 7 Vio; PC 7 Vio
• In measure mode press and move to the mV parameter indicated by the icon
• The display shows the measurement in mV of the pH sensor.
• Scroll on the display of four red bands means that the measurement is not yet stable.
• Consider the measurement truthful only when the stability icon appears .
Note: This measurement is recommended to evaluate the sensor efficiency
ORP Parameter (Redox Potential)
pH 7 Vio; PC 7 Vio
ORP sensors can be used on this series of devices to measure the Oxide-Reduction potential.
Connect the Redox electrode to the BNC type connector marked in green; if necessary, connect the
temperature probe to the RCA / CINCH Temp connector always marked with a green background.
It is possible to calibrate the sensor offset by performing automatic calibration on a predefined point. The
instrument automatically recognizes the Redox solution 475 mV / 25 °C; contact the local distributor to
proceed with the relevant purchase.
The instrument can correct the sensor offset by + 75 mV.
