17
Rev. 1.0 30.01.2020
EN
Temperature measurement ATC MTC
ATC: The direct measurement of the sample temperature for all parameters is carried out through the
NTC 30KΩ probe, which can be either integrated into the sensor (electrode and / or cell) or external.
MTC: If no temperature probe is connected, the value must be changed manually:
keep pressed or until the value starts to flash; then adjust it by continuing to use the
directional keys; then press to confirm.
pH Parameter
pH 7 Vio; PC 7 Vio
On this series of devices, it is possible to use pH sensors with integrated temperature probe or to connect
two different sensors. Connect the pH electrode to the BNC type connector marked in green. Connect the
temperature probe to the RCA / CINCH Temp connector always marked with a green background.
The instrument is also able to recognize the DHS sensor, an innovative electrode that stores calibration data
and that can be used immediately after on any enabled instrument.
pH parameter Setup
In measure mode press to access the SETUP menu.
Press the button to access the pH SETTINGS P1.0 menu
Move with the keys and to select the program you want to access.
The table below shows the setup menu structure for the pH parameter, and for each program the options
that the user can choose and the default value:
Composition of the setup Menu for pH parameter
Program
Description
Options
Factory Default Settings
P1.1
CAL BUFFER SELECT
USA NIST Custom
USA
P1.2
SELECT RESOLUTION
0.1 0.01
0.01
P1.3
STABILITY CRITERIA
LOW MEDIUM - HIGH
MED
P1.6
CALIBRATION DATA
-
-
P1.8
RESET SETTINGS
YES NO
NO
P1.9
TEMPERATURE CAL
YESNO
-
P1.1 pH buffer selection
Access this setup to select the buffer family with which to perform the electrode calibration.
Calibration lines from 1 to 3 points can be made.
During calibration, press to exit and save the points calibrated up to that moment
(see calibration paragraph).
