Xtant 1001DX - Owners Installation Log

OWNER’S INSTALLATION LOG
Upon installation of your mobile audio sound system, your
Authorized Xtant Select Dealer will complete this log. Keep
this owners manual with your vehicle as a reference for all
amplifier settings.
OWNERS NAME:
VEHICLE:
MAKE/MODEL: YEAR:
XTANT AMPLIFIER SERIAL NO.#
CROSSOVER SETTINGS: JUMPER SETTINGS:
LOWPASS FREQ: SLOPE: 12 dB 24 dB
VALUE CODE: PHASE: NORMAL INVERT
HIPASS FREQ
:
RCA OUTPUTS (CIRCLE SETTING)
VALUE CODE: BYPASS HIPASS
SLOPE: 12 dB 24 dB
INPUT SENSITIVITY JUMPER (CIRCLE SETTING)
–20 dB (X .1) –10 dB (X .3) 0 dB (X 1) +10 dB (X 3) +20 dB (X 10)
OUTPUT GAIN ADJUSTMENT PQM-1 YES NO
( DRAW ARROW POSITION )
LFQ 45 YES NO
BLM-1 YES NO
XTANT SELECT DEALER
PHONE:
INSTALLATION SPECIALIST:
DATE INSTALLED:
