Xtant 1001dx SPECIFICATIONS
Frequency Response 5 Hz to 500 Hz +/– 3 dB
Number of Channels 1
Watts per Channel @ 4Ω 1 x 250
Watts per Channel @ 2Ω 1 x 500
Watts per Channel @ 1Ω 1 x 1000
Distortion (THD) < .08%
Signal to Noise Ratio > 88 dB
Damping Factor > 200 @ 100 Hz with 4Ω Load
Input Sensitivity 100 mV to 8.5 V RMS
Unbalanced Source
100 mV to 17 V RMS Balanced Source
Input to Line Output Gain 0 dB +/– 20 dB, Selectable in 10 dB Steps
On-Board Crossover 12 or 24 dB per Octave “Butterworth”
Line Outputs: Yes, High Pass or Bypass Mode
Module Port(s) 1 – Accessory and 1 – Balanced Line
Power Supply Fully Regulated, Pulse Width Modulated
Operational Voltage 11 to 15 Volts
Size (L x W x H) 20.5 x 9.9 x 2.5”
Warranty Limited 4 Year Parts and Labor
SEE PAGE ELEVEN OF THIS MANUAL FOR COMPLETE DETAILS
