ON-BOARD ELECTRONIC CROSSOVER
The 1001dx bass amplifier features a dedicated two-way
electronic crossover. The Low Pass function of the crossover
feeds the 1001dx while the High Pass function supplies signal to the on-board
RCA line outputs. A Bypass function is also available for the line outputs.
The 1001dx’s crossover features independent selection of both crossover fre-
quency and slope (12/24 dB per octave) for the Low and High Pass sections
of the crossover. In addition, the Low Pass section offers a (selectable) 180º
phase inversion for the 1001dx’s output.
Crossover frequency selection is made via a frequency module (SIP)*. The
following Frequency Modules (SIPs) are available from your Xtant Dealer:
50 Hz, 70 Hz, 80 Hz, 90 Hz, 120 Hz, 150 Hz, 300 Hz, 500 Hz, 700 Hz, 1 kHz,
3 kHz, 4 kHz, and 5 kHz.
* SIP: an acronym referring to multiple resistors in a Single In-Line Package
7
