OPTIONAL ACCESSORY MODULES
Xtant optional accessory modules are easily and quickly
installed by your Authorized Xtant Dealer. The upgrade
modules snap into place on the amplifiers PC board when the
top of the unit is removed. These accessories enhance your entire system,
expanding and customizing performance for your unique application.
P
ARAMETRIC EQUALIZATI
ON MODULE – PQM 1
The PQM-1 is a precision tuning instrument, designed to be
adjusted with the use of a Real-Time-Analyzer. This true,
fully adjustable, one band parametric equalizer provides
individual frequency, Q/bandwidth, and +/- 18 dB gain
adjustment controls. By utilizing one of three (3) frequency mod-
ules included, any frequency from 20 Hz to 20kHz can be chosen. The “Q”
ranges from 1 to 10 in value, allowing a wide variety of bandwidth adjust-
ment to address the subtle tuning requirements common to mobile audio sys-
tems. All 1 & 2-channel Xtant amplifiers will accept one PQM-1. All 3/4-chan-
nel amplifiers will accept two PQM-1 modules if desired (one PQM-1 per 2
channels of input).
24 DB / OCTA
VE CROSSOVER MODULE – CM 24X
The CM 24X upgrades the standard on-board crossovers pro-
vided on all Xtant “ix” and “x” Series amplifiers with a 24
dB per octave “Linkwitz - Riley” filter. The CM 24x module
improves loudspeaker polar response while its steeper slope
provides enhanced system design flexibility.
BALANCED LINE MODULE – BLM 1
The BLM 1 upgrades all Xtant “x” and “d” Series amplifiers to
include Balanced / Floating Line Inputs, which are stan-
dard on the 2200ix amplifier. The BLM 1 does not create
balanced line outputs. However, in most cases, the noise
elimination benefits of balanced lines will be passed
through to amplifier(s) connected to these outputs.
8
