16
Adding Accessories Modules
Xtant offers two types of accessory modules which
are designed for either “Horizontal” or “Vertical”
mounting. The docking port(s), located on the amplifi-
er’s circuit board, labeled Horiz Acc Port will accept any module,
while the port(s) labeled “Vert” will only accept modules designed
for vertical mounting. Please refer to the following list for mod-
ule/amplifier compatibility as well as their mounting orientation.
Expansion Module Compatibility
M Series A Series X Series Mounting
NGM 1 yes yes Incl. Horizontal
CM 24x yes yes Incl. Horizontal
PQM 1 yes yes yes Horizontal
LFQ 45 yes yes yes Vertical
CM 12H yes yes N/A Vertical
CM 12L yes yes N/A Vertical
RM 4 no yes Yes Horizontal
RM 8 no yes Incl. Horizontal
RM 12 no yes Yes Horizontal
RM 16 no yes Yes Horizontal
RGM 1 yes yes yes Horizontal
The accessory ports allow you to add the level(s) of signal pro-
cessing that you desire. For example, if a band pass crossover is
desired, a CM 12H (high pass at the lowest frequency of the band
pass) and a CM 12L (low pass at the highest frequency of the band
pass) could be used to create a 12 dB per octave band pass filter.
A more basic set-up would be a PQM-1 EQ module and a CM 12 (L
or H) crossover module.
