FRONT INPUTS REAR INPUTS
OUTPUT GAIN OUTPUT GAIN
FRONT SPEAKERS REAR SPEAKERS
POWER CONNECTOR
OUTPUT GAIN ADJUST
HORIZONTAL ACCESSORY PORTS
VERTICAL ACCESSORY PORTS
INPUT GAIN ADJUST
FRONT CH.
FRONT CH.
REAR CH.
REAR CH.
Standard Features
Regulated, PWM MOSFET Switching Power Supply
Discrete MOSFET Output Circuitry
Front and Rear Input – Balanced Line Circuitry
40 dB of Input Sensitivity – Adjustable in 10 dB Steps
Internally Bridgeable
Four Accessory Module Ports
Low Impedance Protection with Diagnostic LED
Thermal Protection with Diagnostic LED
Limited Four-Year Warranty
Designed, Engineered, and Handcrafted by Xtant in the U.S.A
8
+ – + –
+ – + –
+12
V
GROUND
REMOTE
+ – + – + – + –
GRND RM +12V
SERVICE JUMPER
