Standard Features
Regulated, PWM MOSFET Switching Power Supply
Discrete MOSFET Output Circuitry
Balanced Line Input Circuitry
40 dB of Input Sensitivity – Adjustable in 10 dB Steps
Internally Bridgeable
Two Accessory Module Ports
Low Impedance Protection with Diagnostic LED
Thermal Protection with Diagnostic LED
Limited Four-Year Warranty
Designed, Engineered, and Handcrafted by Xtant in the U.S.A
RCA INPUTS
OUTPUT GAIN
OUTPUT GAIN ADJUST
HORIZONTAL ACCESSORY PORT
VERTICAL ACCESSORY PORT
INPUT GAIN ADJUST
SPEAKER CONNECTOR POWER CONNECTOR
7
+ – + –
+12
V
GROUND
REMOTE
GRND RM +12V
+ – + –
SERVICE JUMPER
