Studer Innotec SA
Xtender
User manual V4.6.0 12
3.6.2
Connection compartment, XTH and XTM models
The unit’s connection compartment must remain permanently closed when in operation.
It is imperative to close the protection cap on the connection terminals after each
intervention in the device.
After opening, check that all sources of AC and DC voltage (batteries) have been
disconnected or put out of service.
Some accessible part inside the compartment can have surface temperature higher than
60°C. Wait for the complete cooling of the unit before opening the compartment.
Any unused cable entry on the device must be sealed to prevent any intrusion. An intrusion
of small animals in the unit may cause serious damage not covered by warranty.
