Studer Innotec SA
Xtender
User manual V4.6.0 46
Elem.
Description
Comment
V
Automatic
earth-neutral
connection
This connection is deactivated by default. In may be used in certain specific
cases for automatically re-establishing the neutral system type TT (TNC, TNS,
TNC-S) when the Xtender is in inverter mode. The activation is carried out via
RCC-02/-03 remote control by configuration of the parameter {1485}. This
operation may only be carried out by qualified personnel, under the
responsibility of these personnel, and in conformity with the local standards
and regulations. See 4.2.3 – p. 18.
W
Galvanic
isolator
This device (optional) is generally used to reduce the risk of electrolytic
corrosion due to the direct current when a boat is connected at the dock.
X
Source
reversing
switch
When the installation has more than one supply source, it is necessary to
install a switching device between the sources, simultaneously switching the
neutral and the phase(s) of these sources. In all cases this device (manual or
automatic) must guarantee interruption of the connected source before its
connection to another source.
Y
Isolation
transformer
This device (optional) prevents the risk of galvanic corrosion due to direct
currents when a boat is connected at the dock.
18 MECHANICAL DIMENSION AND MOUNTING ELEMENTS
Pos.
Description
Comments
25
Mounting hook-up for XTS
Delivered with the unit (without screws for wall mounting)
26
Mounting hook-up for XTH
27
Access shutter to the top
fastening screw
This flap should be resealed after tightening the screws to
prevent small animals that could damage the device from
entering.
19 NAMEPLATE (FIG. 1B)
Pos.
Denomination
Description
Comments
30
Model
Model
31
Pnom*/P30*
Rated power output / power for 30 minutes
with external cooling fan ECF-01
Model XTS only
32
Pnom/P30
Rated power output / power for 30 minutes
33
Udc Battery
Rated battery voltage (accepted input
range)
34
Idc
Charge/inv/inv*
Maximum current in charger/nominal
current in inverter/in inverter with external
cooling fan for XTS model
35
UAC-In
Maximum current at input / output
See sect. 7.2 – p. 26.
36
IAC-In
Rated AC input voltage (input range)
See sect. 7.2.2 – p. 27.
37
UAC-Out
Rated output voltage in inverter mode
(possible adjustment range in inverter
mode)
When the transfer relay is
activated, the AC output
voltage is equivalent to AC
input voltage
38
I AC-Out
Inv/Inv*/max
Maximum charger current
See sect. 7.2.2 – p. 27.
39
SN:xxxxxxxxxx
Serial no.
40
IPxx
Protection rating according to IEC 60529
