Xterra FS3.9e User Manual

5
3 HARDWARE STEP 3
4 HARDWARE STEP 4
#105. 5/16” × 7T_
Nyloc Nut (2 pcs)
#89. 3/8” × 7T_
Nyloc Nut (2 pcs)
#71. 5/16” × 32m/m_
Hex Head Bolt (2 pcs)
#94. 3/8” × 19 × 1.5T_
Flat Washer (2 pcs)
#98. 5/16” × 20 × 1.5T_
Flat Washer (4 pcs)
#77. 3/8” × 2-1/4”_
Button Head Socket Bolt (2 pcs)
#76. 5/16” × 3/4”_
Button Head Socket Bolt (2 pcs)
#84. Ø 3.5 × 12m/m_
Sheet Metal Screw (8pcs)
#79. M5 × 15m/m_
Phillips Head Screw (8pcs)

Xterra FS3.9e Specifications

General

Brand	Xterra
Model	FS3.9e
Category	Elliptical Trainer
Language	English
