Xterra FS5.5e / 5.7e Elliptical
6
#146 - 5/16" x 23mm
Flat Washer (2pcs)
#107 - 5/16" x 15mm
Hex Head Bolt (2pcs)
#152 - 17mm
Wave Washer (2pcs)
#125 - 3.5 x 12mm
Sheet Metal Screw (6pcs)
#125 - 3.5 x 12mm
Sheet Metal Screw (8pcs)
#124 - M5 x 15mm
Phillips Head Screw (18pcs)
#109 - 5/16"x 1-1/4”
Hex Head Bolt (2pcs)
#136 - 5/16" x7T
Nyloc Nut (2pcs)
#146 - 5/16" x 23 x 1.5T
Flat Washer (2pcs)
#164 - M6 x 10mm
Phillips Head Screw (4pcs)
Step 2
Step 3
Step 4
