5 Xterra FS5.5e / 5.7e Elliptical
ASSEMBLY PACK CHECK LIST
Step 1
#112 - 3/8" x 1-1/2"
Hex Head Bolt (2pcs)
#149 - 3/8" x 19 x 1.5T
Flat Washer (2pcs)
#146 - 5/16" x 23 x 1.5T
Flat Washer (4pcs)
#123 - M5 x 10mm
Phillips Head Screw (4pcs)
#155 - 3/8" x2T
Split Washer (1pc)
#110 - 5/16" x 2-1/4"
Hex Head Bolt (4pcs)
#111 - 3/8" x 3/4"
Hex Head Bolt (2pcs)
#154 - 5/16" x1.5T
Split Washer (4pcs)
#156 - 5/16"
Star Washer (4pcs)
#139 - 3/8" x7T
Nyloc Nut (2pcs)
#113 - 3/8" x 2-1/4"
Hex Head Bolt (1pc)
#153 - 3/8" x 23 x 2T
Curved Washer (2pcs)
