VESDA Accessories Guide
4.5.3 Specifications
Supply Voltage 18 to 30 VDC
Power Consumption Power Consumption (W) @24
VDC
Silent With Alarm
Power 1.44 W 2.52 W
Current 60 mA 105 mA
Dimensions (WHD) 105 mm (4.1 in.) x 130 mm (5.3 in.) x 26 mm (1.02 in.)
Dimensions in Remote Mounting
Unit
140 mm (5.5 in.) x 150 mm (5.9 in.) x 85 mm (3.4 in.)
Operating Temp. 0° to 39°C (32° F to 103° F)
Humidity 10-99%RH non-condensing
Software Compatibility Version:
VLP detector - Ver. 3.05.00 and later.
VLS detector - Ver. 3.05.00 and later.
VLC detector -Ver. 3.07.05 and later.
High Level Interface (HLI) - Ver. 3.05.04 and later.
LCD Programmer - Ver. 3.02.*1 and later(*denotes language). The
LCD Programmer cannot configure the system relay module.
Displays - do not need upgrading VSM4 - Ver. 3.00.06 and later.
VSC - Ver. 3.00.06 and later.
4.5.4 Mounting the System Relay Module
The system relay module is mounted onto a remote box. For details on mounting refer to Mounting a Remote
Box on page 8.
4.5.5 Wiring the System Relay Module
The relay processor card in a system relay module is connected to a 7 relay remote termination card. For
details on wiring the system relay module please refer to Wiring Remote Systems on page 11.
